Additional information
| Variants | BE-TA5502.02, BE-TA5502.G2, BE-TA5504.02, BE-TA5504.G2, BE-TA5506.02, BE-TA5506.G2, BE-TA5508.02, BE-TA5508.G2 |
|---|---|
| Brands | MDT |
Description
The MDT Push-button 55 is a clearly arranged KNX push-button with horizontally arranged 2 button operation. It features almost all the functions of the binary input and is designed for flush-mounted installation. By simply pressing a button, the push-button can call up parameterised functions such as scenes or the dimming function. A separate labelling field is available for labelling the key functions. Middle text field with cover foil for individual labelling. Push-buttons can be programmed for 1 or 2 button operation. Single- and double button operation for Switching, Dimming, Blinds, Values. Innovative group control with long / extra long operation. Value / Scenes toggle with up to 4 values. Short / long button push and 2 objects. 4 Logic blocks.Installation in an installation box with included support ring. Integrated bus coupler. 3 years warranty. Made in Germany.
The MDT Push-buttons 55 fit into the switch lines of leading manufacturers, such as:
- GIRA Standard 55, E2, E22, Event, Esprit
- BERKER S1, B3, B7
- JUNG A 500, A PLUS, A CREATION, AS 500, A550, A FLOW
- MERTEN 1M, M-Smart, M-Plan, M-Pure
Colour: Pure white matt, Pure white gloss.
Functional Areas: 2-fold, 4-fold, 6-fold, 8-fold.
Downloads
| Technical Documentation | Date | Version | Downloads |
| Productdatabase ETS5/6 | 06/23 | V2.0 | knxprod |
| Functional overview | |||
| Datasheet | |||
| Assembly and operational instructions | |||
| Technical manual | 08/23 | V1.0 | |
| Print template with icons. Requires Adobe Acrobat Reader | zip | ||
| Tender texts | Link | ||
Available Variants of this series:
Push-button 55 | Series .02
Colour: Pure white matt; Functional Areas: 2-fold
Push-button 55 | Series .02
Colour: Pure white gloss; Functional Areas: 2-fold
Push-button 55 | Series .02
Colour: Pure white matt; Functional Areas: 4-fold
Push-button 55 | Series .02
Colour: Pure white gloss; Functional Areas: 4-fold
Push-button 55 | Series .02
Colour: Pure white matt; Functional Areas: 6-fold
Push-button 55 | Series .02
Colour: Pure white gloss; Functional Areas: 6-fold
Push-button 55 | Series .02
Colour: Pure white matt; Functional Areas: 8-fold
